Checklist for designing a sluice gate drive
For a quotation kindly fi ll in at least the details marked with *.
Company: .................................................................................................................................................
Street / No.: ...................................................................Contact ...............................................................
Postcode / Place: ..........................................................Department ........................................................
Phone. ........................................Fax......................................Email.................. ......................................
1. Dimension definition
Please defi ne the dimensions for your project using the sketch and enter them in the following table.
If the reinforcement systems are different, please complete one checklist per sluice gate drive.
View: „V“
Rack jack
Sluice gate
Flow direction
* Required number of sluice gate drives:...............
* 1.1 Sluice gate guide:
Steel/Wood Steel/Steel Steel/Plastic Steel/Rubber seal Roller guide
1.2 Material for sluice gate: Wood Steel Thickness: ............. mm
* 1.3 Sluice gate width X = .............. mm
* 1.4 Sluice gate height Y = .............. mm
* 1.4.1 Water storage level Z = .............. mm
* 1.5 Total weight of the sluice gate G = .............. kg
1.6 Winch spacing for double sluice gate drive K = .............. mm
* 1.7 Dimension A (sluice gate, top) A = ............... mm
*1.8 Required lift H = .............. mm
1.9 Dimension B B = .............. mm
1.9 Dimension C C = .............. mm
1.10 Dimension D D = .............. mm
1.11 Bore hole diameter U = .............. mm
